Chapter 5
PRODUCT OUTLOOK
Right View (GT-70X)
Left: Fiber-optic connector, Right: TP connector.
Three LED indicators per TP, ber port.
Rear View (GT-70X)
One DC jack for DC power input and DIP switch to disable/enable
Auto by pass function.
Notice:
Please to note that if converter is connect
with switch which is Auto negotiation, must
enable the Auto by pass function.
If both devices are conveters must disable
the Auto by pass function.
