G31-M7 TE
39
SPEC
Złącze IDE x1 Każde złącze obs ługuje 2 urządzenia IDE
Złącze SATA x4 Każde złącze obs ługuje 1 urządzenie SATA
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze głó wkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze głó wkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze główkowe kasowania CMOS x1
Złącze USB x2
Każde złącze obs ługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącze zas ilania (4 pinowe) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
179 mm (S) X 235 mm (W)
Obsluga
systemu
operacyjne
go
Windows 2000 / XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego sys temu
operacyjnego bez powiado mienia.
