![Biostar J1900NH3 Версия 6.1/6.3 [30/33] Polish](/views2/1710718/page30/bg1e.png)
Motherboard Manual
28
Polish
Specyfikacje techniczne
Obsługa
procesora
J1800NH3: Intel® Celeron® J1800
J1900NH3: Intel® Celeron® J1900
J2900NH3: Intel® Pentium® J2900
Pamięć
Pojedynczy pamięci DDR3L 1333 Dwukanałowa (1.35V/1.5V)
2x DDR3L SO-DIMM Pamięć Gniazda procesora (Slot), Maksymalna wielkość
pamięci 16 GB
Każdy DIMM obsługuje jeden moduł non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L
* Proszę sprawdzić listę obsługiwanych pamięć na stronie internetowej
www.biostar.com.tw
Przechowywanie Złącze 2x SATA 3Gb/s, Obsługa rodzimy IDE & AHCI tryb
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb auto negocjacja, pojemność dupleks Połowe / Pełny
Codec Audio
ALC662
Kanały Audio wysokiej Definicji 5.1
USB
6 x złącza USB 2.0 (4 przez tylne porty wejścia/ wyjścia oraz 2 przez
wewnętrzne porty)
1x złącza USB 3.0 (1 przez tylne porty wejścia)
Złącza
rozszerzeń
złącza 1x PCIe x1
Tylne porty
wejścia/ wyjścia
Myszka 1x PS/2
Klawiatura 1x PS/2
Porty 1x HDMI (gniazdo)
Porty 1x VGA
Porty 1x LAN
Porty 1x USB 3.0
Porty 4x USB 2.0
Porty audio 3x
Wewnętrzne porty
wejścia/ wyjścia
Złącza 2x SATA 2.0Gb/s
Złącza 2x USB 2.0 (każde złącze obsługuje dodatkowe 2 porty USB 2.0)
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora obudowy x2
Złącze przedniego panelu x1
Złącze audio przedniego panelu x1
Złącze bezpośrednie CMOS x1
Złącze port drukarki x1
Port szeregowy x1
Obudowa Obudowa Mini-ITX, 170 mm x 170 mm
Obsługa OS
Windows 7 / 8 / 8.1
Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z
wypowiedzeniem lub bez wypowiedzenia.
