Motherboard Manual
30
Russian
Спецификации
Поддержка
центрального
процессора
J1800NH3: Intel® Celeron® J1800
J1900NH3: Intel® Celeron® J1900
J2900NH3: Intel® Pentium® J2900
Память
Поддерживает двухканальный DDR3L 1333 (1.35V/1.5V)
2 гнезда платы памяти DDR3L SO-DIMM, максимальная память до 16 Гб
Каждый модуль DIMM поддерживает модуль не-ECC 512 Мб/ 1/ 2/ 4/ 8 Гб
DDR3L
* Перечень поддержки памяти смотрите на www.biostar.com.tw
.
Накопитель Соединитель 2x SATA 3 Гб/с, Поддерживает родной IDE & AHCI режим
Локальная сеть
Realtek RTL 8111G
Автосогласование 10/ 100/ 1000 Мб/с, работает в полно/полудуплексном
режиме
Аудиокодек
ALC662
Каналы 5.1, высококачественное аудио
USB
6 порта USB 2.0 (4 сзади ввода-вывода и 2 через внутренние контакты)
1 порта USB 3.0 (1 сзади ввода-вывода)
Гнезда расшир. 1x PCIe x1 гнездо
Задняя плата
ввода-вывода
1 мышь PS/2
1 клавиатура PS/2
1 порт HDMI
1 порт VGA
1 порт локальной сети
1 порта USB 3.0
4 порта USB 2.0
3 гнезд для подключения наушников
Внутр. Плата
ввода-вывода
Соединитель 2x SATA 3 Гб/с
2 контакта USB 2.0 (каждый контакт поддерживает 2 порта USB 2.0)
1 4-выводный разъем питания
1 24-выводный разъем питания
2 разъема вентилятора системы
1 контакт передней панели
1 контакт передней аудиопанели
1 контакт микросхемы Clear CMOS
1 контакт порта принтера
1 контакт последовательного порта
Конструктив Форм-фактор Mini-ITX, 170мм x 170 мм
Поддержка ОС
Windows 7 / 8 / 8.1
Biostar оставляет за собой право добавлять или удалять поддержку
любой ОС, с уведомлением или без.
