Biostar B45M2 Версия V6.x [12/67] Ryzen ddr maximum frequency support table

12 | Chapter 2: Hardware installaon

Ryzen - DDR Maximum Frequency Support Table

▪

Ryzen - Pinnacle Ridge:

Maximum Frequency DIMMA1 DIMMB1

DDR4-2933 -- SR

DDR4-2933 SR --

DDR4-2933 SR SR

DDR4-2400 -- DR

DDR4-2400 DR --

DDR4-2400 DR DR

▪

Ryzen - Summit Ridge:

Maximum Frequency DIMMA1 DIMMB1

DDR4-2666 -- SR

DDR4-2666 SR --

DDR4-2666 -- DR

DDR4-2666 DR --

DDR4-2666 SR SR

DDR4-2666 DR DR

▪

Ryzen - Raven Ridge:

Maximum Frequency DIMMA1 DIMMB1

DDR4-2933 -- SR

DDR4-2933 SR --

DDR4-2666 -- DR

DDR4-2666 DR --

DDR4-2666 SR SR

DDR4-2400 DR DR

Note

 SR-Single-rankDIMM,1Rx4or1Rx8.



DR-Dual-rankDIMMs,2Rx4or2Rx8.



ForthebeerDDR4modulecompability,pleasefollowthetabletoinstallyourDDR4modules.
