Biostar B45M2 Версия V6.x [5/67] Rear panel connectors

Chapter 1: Introducon | 5

B45M2

1.4 Rear Panel Connectors

Note



HDMI/VGAoutputrequireanAMDfamilyprocessorwithintedratedgraphics.



SincetheaudiochipsupportsHighDenionAudioSpecicaon,thefunconofeachaudiojack

canbedenedbysoware.Theinput/outputfunconofeachaudiojacklistedaboverepresents

thedefaultseng.However,whenconnecngexternalmicrophonetotheaudioport,pleaseuse

theLineIn(Blue)andMicIn(Pink)audiojack.



Maximumresoluon

HDMI:4096x2160@24Hz,compliantwithHDMI1.4

VGA:1920x1200@60Hz



WhenusingthefrontHDaudiojackandplugintheheadset/microphone,therearsoundwillbe

automacallyDisabled.
