Biostar A55ML+ Версия 6.x [41/53] A55ml a55mg

A55ML+ /A55MG+

SPECIFICA

Collettore ventolina sistema x1 Alimentazione ventolina d i sis tema

Collettore cancellaz ione CMOS x1

Connettore USB2.0 x2

Ciascun connettore supporta 2 porte USB2.0

pannello frontale

Connettore Porta stampante x1 Ciascun connettore supporta 1 Porta stampante

Porta seriale x1

Connettore alimentazione x1

(24 pin)

Connettore alimentazione x1

(4pin)

I/O

pannello

posteriore

Tas t iera PS /2 x 1

Mouse PS/2 x1

Porta VGA x1

Porta DVI-D x1

Porta LAN x1

Porta USB2.0 x4

Connettore audio x3

Dimension

i scheda

190 mm (larghezza) x 244 mm

(altezza)

Sistemi

operativi

supportati

Windows XP / Vista / 7

Biostar si riserva il diritto di aggiungere o

rimuovere il supporto di qualsiasi sistema

operativo senza preavviso.
