Biostar A55ML+ Версия 6.x [6/53] Otherboard

Motherboard Manual

1.5 MOTHERBOARD LAYOUT

KBMS1

VGA1

DVI1

USB1

RJ45USB1

AUDIO1

Super

I/O

Codec

CPU_FAN1

PCI1

PEX16_1

PEX1_1

PEX1_2

F_AUDIO1

J_COM1

J_PRINT1

PAN EL1 F_USB2 F_USB1

SATA1

SYS_FAN1

SATA3

SATA4

SATA2

AMD

A55

BIOS

JCMOS1

BAT1

LAN

DDR3_A1

DDR3_B1

ATXPWR1

ATXPWR2

Note: represents the 1■

pin.
