TA880GB+/TA880GB

B. Memory Capacity

DIMM Socket

Location

DDR3 Module

Total Mem ory

Size

DDR3_A1 512MB/1GB/2GB/4GB

DDR3_B1 512MB/1GB/2GB/4GB

DDR3_A2 512MB/1GB/2GB/4GB

DDR3_B2 512MB/1GB/2GB/4GB

Max is 16GB.

C. Dual Channel Memory installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status

DDR3_A1

DDR3_B1 DDR3_A2 DDR3_B2

Enabled O O X X

Enabled X X O O

Enabled O O O O

(O means memory installed, X means memory not installed.)

The DRAM bus width of the memory module must be the same (x8 or

x16)
