Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Phenom II / Athlon II
processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 880G
AMD SB710
Super I/O
ITE 8721
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
H/W Mon itor
Fan Sp eed Contro ller
ITE's "Smart Guard ian" function
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
Graphics
AMD 880G (Radeon HD4250)
Max Shared V id eo Memory is 512 MB
DVI/HDMI/UVD /HDCP support
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 spe cif ic at ion co mp liant.
RAID 0,1,10 support
LAN
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC892
5.1channels audio out
Supports HD Audio
PCI Slot x2 Supports PCI expansion cards
Slots
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16 expansion card
SATA Connector x6 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
S/PDIF out Connector x1 Supports digital audio out function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x2 System Fan Power supply
On Board
Connectors
CMOS clear Header x1 Restore CMOS data to factory default
