A880G+/TA880G/A785G3+ BIOS Manual
25
Internal Graphics Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics Configuration
UMA Frame Buffer Size [Auto]
GFX Engine Clock Override [Disable]
FB Location [Above 4G]
Internal Graphics Mode [UMA]
Surround View [Disabled]
Options
Disable
UMA
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics device.
Options: UMA (Default) / Disable
UMA Frame Buffer Size
This item allows you to choose the UMA frame buffer size for internal graphics.
Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB
GFX Engine Clock Override
This item allows you to control the internal GFX engine clock override function.
Options: Disabled (Default) / Enabled
GFX Engine Clock
This item allows you to set the internal GFX engine clock.
Options: 500 (Default) / Min: 150, Max: 1200
Surround View
This item allows you to control the Surround View Function.
Options: Disabled / Enabled / Auto (Default)
FB Location
This item allows you to set the FB-DIMM location.
Options: Above 4G (Default) / Under 4G
