A880G+/TA880G/A785G3+ BIOS Manual
34
Hyper Transport Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Hyper Transport Configuration
NODE0:PCI-X2 HT Link
HT Link Speed [Auto]
HT Link Width [Auto]
The Hypertransport
link will run at this
speed if it is slower
than or equal to the
system clock and the
board is capable.
Performance
HT Link Speed
Options: Auto (Default) / 200MHz / 400MHz / 600MHz / 800MHz / 1GHz /
1.2GHz / 1.4GHz / 1.6GHz / 1.8GHz / 2.0GHz
HT Link Width
Options: Auto (Default) / 4 Bit / 8 Bit / 16 Bit
