A880G+/TA880G/A785G3+ BIOS Manual
26
PCI Express Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Configuration
> Port #07 Features
> NB-SB Port Features
> Port #02 Features
Port #02/07 Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mode [Disabled]
Link ASPM [Disabled]
Link Width [Auto]
Slot Power Limit,W [75 ]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Disabled (Default) / Auto
Link ASPM
Options: Disabled (Default) / L0s / L1 / L0x & L1
