Motherboard Manual
30
FRENCH
SPEC
UC
Socket AM3
Processeurs AMD Phenom II/ Athlon II
(Watt maximum : 95W)
L'architecture AMD 64 permet le calcul 32 et 64 bits
Prend en charge Hyper Transport 2.0
Bus frontal
Prend en charge Hyper Transport 2.0
jusqu'à une bande passante de 2.0 GT/s
Chipset
GeForce 6150 SE/nForce 430 (MCP6P3)
GeForce 7025/nForce 630a (N68S3)
Super E/S
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faible compte de broches
Initiatives de contrôle environnementales,
Moniteur de matériel
Contrôleur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémoire maximale de 8 Go
Chaque DIMM prend en charge des DDR3
de 512Mo/1Go/2Go/4Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 800 / 1066 / 1333
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
Graphiques
GeForce 6150 SE/nForce 430 (MCP6P3)
GeForce 7025/nForce 630a (N68S3)
Mémoire vidéo partagée maximale de 512 Mo (under
OS)
IDE Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100 / 133
Prend en charge le mode PIO 0~4,
SATA II
Contrôleur Serial ATA
intégré :
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécification SATA Version 2.0
LAN Realtek RTL 8201CL
10 / 100 Mb/s négociation automatique
Half / Full duplex capability
Codec audio
ALC662 / VT1708B
Sortie audio à 5.1 voies
Prise en charge de l'audio haute definition
Fente PCI x2
Fentes
Slot PCI Express x16 x1
Connecteur de disquette x1
Chaque connector prend en charge 2 lecteurs de
disquettes
Connecteur de Port d'imprimante x1 Chaque connector prend en charge 1 Port d'imprimante
Connecteur
embarqué
Connecteur IDE x1
Chaque connecteur prend en charge 2 périphériques
IDE
