Biostar N68S3 Версия 6.x [6/47] Otherboard

Motherboard Manual

1.5 MOTHERBOARDLAYOUT

Socket AM3

ATXPWR2

KBMS1

VGA1

USB1

JUSBV1

JKB_PWR

COM1

RJ45USB1

AUDIO1

ATXPWR1

F_AUDIO1

BAT1

Codec

LAN

JPRINT1

JSPDIFOUT1

FDD1

PEX16_1

PCI2

Super I/O

PCI1

SYS_FAN1

PANEL1

SATA1 SATA3

SATA4SATA2

JCMOS1

BIOS

F_USB1

F_USB2

JUSBV2

IDE1

CPU_FAN1

DDR3_A1

DDR3_B1

GeForce

6150 SE/7025

nForce

430/630a

Note: represents the 1■

pin.
