MCP6P3/N68S3
39
SPEC
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia audio
Złącze główkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze główkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze główkowe kasowania
CMOS x1
Złącze USB x2
Każde złącze obsługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącze zasilania (4 pinowe) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS/2 x1
Port VGA x1
Port szeregowy x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
190 mm (S) X 244 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 0+1 / 5
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
BIOSTAR zastrzega sobie prawo dodawania lub
odwoływania obsługi dowolnego systemu
operacyjnego bez powiadomienia.
