Motherboard Manual
34
SPANISH
Especificación
CPU
Conector AM3
Procesadores AMD Phenom II/ Athlon II
(Vatio máximo: 95W)
La arquitectura AMD 64 permite el procesado de 32 y
64 bits
Soporta las tecnologías Hyper Transport 2.0
FSB
Admite HyperTransport 2.0 con un ancho
de banda de hasta 2.0 GT/s
Conjunto de
chips
GeForce 7025/nForce 630a
Súper E/S
ITE 8721
Le ofrece las funcionalidades heredadas de
uso más común Súper E/S.
Interfaz de cuenta Low Pin
Iniciativas de control de entorno,
Monitor hardware
Controlador de velocidad de ventilador
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 8GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800 / 1066 / 1333
No admite DIMM registrados o DIMM compatibles con
ECC
Gráficos GeForce 7025/nForce 630a
Memoria máxima de vídeo compartida de 512MB
(under OS)
IDE Controlador IDE integrado
Modo bus maestro Ultra DMA 33 / 66 / 100 / 133
Soporte los Modos PIO 0~4,
SATA II Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3 Gb/s.
Compatible con la versión SATA 2.0.
Red Local Realtek RTL 8201CL
Negociación de 10 / 100 Mb/s
Funciones Half / Full dúplex
Códecs de
sonido
ALC662 / VT1708B
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
Ranura PCI X2
Ranuras
Ranura PCI Express x16 X1
Conector disco flexible X1 Cada conector soporta 2 unidades de disco flexible
Conector Puerto de impresora X1 Cada conector soporta 1 Puerto de impresora
Conector IDE X1 Cada conector soporta 2 dispositivos IDE
Conectores
en placa
Conector SATA X4 Cada conector soporta 1 dispositivos SATA
