Motherboard Manual
44
JAPANESE
仕様
CPU
Socket AM3
AMD Phenom II/ Athlon II プロセッサ
(最高のワット: 95W)
AMD 64アーキテクチャでは、32ビットと64ビット計算が可
能です
ハイパートランスポート2.0サポートします
FSB
2.0 GT/sのバンド幅までハイパートランスポ
ート2.0をサポートします
チップセット GeForce 7025/nForce 630a
メインメモリ
DDR3 DIMMスロット x 2
最大メモリ容量8GB
各DIMMは 512MB/1GB/2GB/4GB DDR3を
サポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800 / 1066 / 1333 をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE 8721
もっとも一般に使用されるレガシーSuper I/O
機能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
グラフィック
ス
GeForce 7025/nForce 630a 最大の共有ビデオメモリは512MBです(under OS)
IDE 統合IDEコントローラ
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
SATA II 統合シリアルATAコントローラ
最高3 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN Realtek RTL 8201CL
10 / 100 Mb/秒のオートネゴシエーション
半/全二重機能
サウンド
Codec
ALC662 / VT1708B
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
PCIスロット x2
スロット
PCI Express x16スロット x1
フロッピーコネクタ x1 各コネクタは2つのフロッピードライブをサポートします
プリンタポートコネクタ x1 各コネクタは1つのプリンタポートをサポートします
オンボードコ
ネクタ
IDEコネクタ x1 各コネクタは2つのIDEデバイスをサポートします
