Biostar TA790XE3 Версия 6.x [20/65] Cd_in1 cd rom audio in connector

Motherboard Manual

CD_IN1: CD-ROM Audio-in Connector

This connector allows user to connect the audio source from the variaty devices,

like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc.

Assignment

1 Left Channel Input

2 Ground

3 Ground

4 Right Channel Input

J_COM1: Serial port Connector

The motherboard has a Serial Port Connector for connecting RS-232 Port.

Assignment

1 Carrier detect

2 Received data

3 Transmitted data

4 Data terminal ready

5 Signal ground

6 Data set ready

7 Request to send

8 Clear to send

9 Ring indicator

210

10 NC
