1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Sempron / Athlon / Athlon II / Phenom
/ Phenom II processors
Maximum Watt: 95W (A780L M2G+/
A780L M2L+)
Maximum Watt: 125W (A780L)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 3.2 GT/s Bandwidth
Chipset
AMD RS780L
AMD SB710
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "S mart Guard ian" funct ion
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory modu le
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+/AM3 CPU)
Registered DIMM and ECC D IMM is not supported
Graphics Integrated in AMD RS780L Chipset
Max Shared V id eo Memory is 512 MB
DVI support
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specificat ion co mp liant
LAN
Realtek RTL 8111DL (A780L M2G+)
Realtek RTL 8102EL (A780L M2L+/A780L)
10 / 100 / 1000 Mb/s auto negotiation
10 / 100 Mb/s auto negotiation
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 slot x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
On Board
Connectors
SATA Connector x4 Each connector supports 1 SATA devices
