Biostar A780L M2L+ Версия 6.x [6/49] Otherboard

Motherboard Manual

1.5 MOTHERBOARD LAYOUT

KBMS1

USB1

RJ45USB1

VGA1

DVI1

AUDIO1

JUSBV1

F_AUDIO1

LAN

Super

I/O

Codec

PEX16_1

PCI1

PCI2

FDD1

JUSBV2

J_PRINT1J_COM1

PANEL 1

F_USB2

F_USB1

SATA1 SATA2

SYS_FAN1

SATA3

SATA4

BIOS

IDE1

ATXPWR1

DIMMA1

DIMMB1

CPU_FAN1

BATTERY

ATXPWR2

Socket AM2+

AMD

RS780L

AMD

SB710

JCMOS1

JSPDIFOUT1

(A780L M2G+ Only)

Note: represents the 1■

pin.
