Chapter 10

FT-80X Technical Specifications

The FT-80X comes with the following standard features:

· Standard: IEEE802.3/u, 10/100Base-TX and 100Base-

· Connectors:

ð One RJ-45 (Auto-MDI/MDI-X) Twisted Pair, EIA568

ð One Fiber-optic, 1310nm wavelength (except: FT-

806A/FT-806B), connector-type vary with model

· Data Transfer Rate: 10/100Mbps (TP), 100Mbps (FX)

· Duplex mode support: Full or half-duplex mode by

Auto-Negotiation (TP)

· LED indicators: PWR, FX LNK/ACT, FX FDX/COL TP 100,

TP LNK/ACT, TP FDX/COL

· Power Requirement: 5V DC, 2A

· Ambient Temperature: 0° to 50°C (operating)

· Humidity: 5% to 90% (non-condensing)

· Dimension: 26 x 70 x 97mm (HxWxD)

· Cable:

ð UTP: Cat 5 UTP cable

ð Fiber: MM: 50/125 µm or 62.5/125 µm optic fiber

ð Fiber: SM: 8.3/125, 8.7/125, 9/125 µm optic fiber

Connecting to Router, Bridge, or Switch, Hub, please refer to the

device’s Technical Manual.
