NF520B A2G+
29
SPECIFICA
Connettore floppy x1 Ciascun connettore supporta 2 unità Floppy
Connettore Porta stampante x1 Ciascun connettore supporta 1 Porta stampante
Connettore IDE x1
Ciascun connettore supporta 2 unità IDE
Connettore SATA x2
Ciascun connettore supporta 1 unità SATA
Connettore pannello frontale x1
Supporta i servizi del pannello frontale
Connettore audio frontale x1
Supporta la funzione audio pannello frontale
Connettore CD-in x1
Supporta la funzione input audio CD
Connettore output SPDIF x1
Collettore ventolina C PU x1
Alimentazione ventolina CPU (con funzione Smart
Fan)
Collettore ventolina sistema x1
Alimentazione ventolina di sistema
Collettore cancellaz ione CMOS x1
Connettore USB x2
Ciascun connettore supporta 2 porte USB
pannello frontale
Connettore alimentazione x1
(24 pin)
Connettori
su scheda
Connettore alimentazione x1
(4 pin)
I/O
pannello
posteriore
Tas t ier a PS /2 x 1
Mouse PS/2 x1
Porta seriale x1
Porta LAN x1
Porta USB x4
Connettore audio x3
Dimension
i scheda
200 mm (larghezza) x 293 mm
(altezza)
Caratterist
iche
speciali
Supporto RAID 0 / 1
Sistemi
operativi
supportati
Windows XP / Vista 32 / 64 / Windows
7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
