Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 x2
/ Sempron / Phenom / Phenom II processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit computing
Supports Hyper Transport and Cool=n=Quiet
FSB
Support HyperTransport 2.0
Supports up to 2.0 GT/s Bandwidth
Chipset
nVIDIA nForce 520LE
Super I/O
ITE 8718
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
H/W Monitor
Fan Sp eed Contro ller
ITE's "S mart Guard ian" function
Main
Memory
DDR2 DIMM Slot x 4
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Max Memory Capicity 16GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533/667/800
Supports DDR2 1066 (by AM2+ / AM3 CPU)
Registered DIMM and ECC DIMM is not supported
IDE
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specificat ion co mp liant.
LAN
Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC662
5.1 channels audio out
Supports HD Audio
PCI Slot x3 Supports PCI expansion cards
PCI Express x16 Slot x1 Supports PCI-E x16 expansion card
Slots
PCI Express x 1 Slot x1 Supports PCI-E x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
On Board
Connectors
IDE Connector x1 Each connector supports 2 IDE device
