Motherboard Manual
40
PORTUGUESE
ESPECIFICAÇÕES
CPU
Socket AM2+
Processadores AMD Athlon 64 / Athlon 64
FX / Althlon 64 X2 / Sempron / PhenomX3
(Watt máximo: 95W)
A arquitectura AMD 64 p ermite u ma co mputação de
32 e 64 bits
Suporta as tecnolog ias Hyper Transport 3.0 e
PowerNow
FSB
Suporta a tecnologia HyperTransport 3.0
com uma largura de banda até 5.2 GT/s
Chipset GeForce 8100
Especificaç
ão Super
I/O
ITE 8718
Proporciona as funcionalidades mais
utilizadas em termos da especificação
Super I/O.
Interface LPC (Low Pin Count).
In iciat ivas par a contro lo do amb iente
Monitorização do hardware
Função "Smart Guard ian" da ITE
Memória
principal
Ranhuras DIMM DDR2 x 2
Capacidad e máx ima d e memór ia: 8 GB
Cada módulo DIMM suporta uma
memória DDR2 de 256MB/512MB/
1GB/2GB/4GB
Módulo de memória DDR2 de canal duplo
Suporta módulos DDR2 533 / 667 / 800
Suporta módulos DDR2 1066 (by AM2+ CPU)
Os módulos DIMM registados e os DIMM ECC não são
suportados
Placa
gráfica
Integrada no chipset GeForce 8100
Memória de vídeo máxima partilhada: 512 MB
Suporta as funções DX10 / HDCP / PureV ideo
IDE Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
SATA Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidad e co m a especificação SATA versão 2.0.
LAN Realtek RTL 8111C
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Suporte
para áudio
de alta
definição
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
Ranhura PCI Express Gen2 x16 x1
Ranhuras
Ranhura PCI x2
Conector da unidade de disquetes x1 Cada conector suporta 2 unidades de disquetes
Conector IDE x1 Cada conector suporta 2 dispositivos IDE
Conector SATA x4 Cada conector suporta 1 dispositivo SATA
Conectores
na placa
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
