Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
VGA
JKBMS
DVI
JUSB1
JUSBLAN2
JAUDIO1
BAT1
J AUDI OF
LAN
Codec
JCOM JPRNT
FDD
PCI2
PCI1
PEX16_1
J CDIN
SATA1 SATA3
SATA2 SATA4
JSFAN
JPANEL1
Super I/O
BIOS
JCMOS
JUSB2 JUSB3JUSB4
JUSB PW R1
JCFAN
GeForce
8100
IDE
JATXPWR1
DIM MB1
DIM MA1
JUSBPWR2
JKB_PWR
JATXPWR2
Socket AM2+
Note: represents the 1■
st
pin.
