GF8100 M2G+
41
ESPECIFICAÇÕES
Conector de áud io frontal x1 Suporta a função de áudio no painel frontal
Conector para entrada de CDs x1 Suporta a entrada de áudio a part ir de CDs
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função
Smart Fan)
Conector da ventoinha do s istema x1 Alimentação da ventoinha do s istema
Conector para limpeza do CMOS x1
Conector USB x3 Cada conector suporta 2 portas USB no painel frontal
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Conector da Porta série x1
Entradas/S
aídas no
painel
traseiro
Tec l ado PS /2 x 1
Rato PS/2 x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Porta DVI x1
Tamanho
da placa
175 mm (L) X 245 mm (A)
Característi
cas
especiais
Suporta as funções RAID 0 / 1 / 5 / 0+1
Suporta as funçõ es Hybrid SL I (by nV IDIA
driver)
Sistemas
operativos
suportados
Windows XP / VISTA
A Biostar reserva-se o direito de adicionar ou remover
suporte para qualquer sistema operativo com ou sem
av iso prév io.
