GF7025-M2 TE/GF7050-M2 SE
31
GF7025-M2 TE GF7050-M2 SE
Codec audio
ALC662
Sortie audio à 5.1 voies
Prise en charge de l'audio haute definition
ALC662
Sortie audio à 5.1 voies
Prise en charge de l'audio haute definition
Fente PCI x2 Fente PCI x2
Fentes
Slot PCI Express x16 x1 Slot PCI Express x16 x1
Connecteur de disquette x1 Connecteur de disquette x1
Connecteur de Port d'imprimante x1 Connecteur de Port d'imprimante x1
Connecteur IDE x1 Connec teur IDE x1
Connec t eur SATA x4 C onnect eur SATA x4
Connecteur du panneau avant x1 Connecteur du panneau avant x1
Connecteur Audio du panneau avant x1 Connecteur Audio du panneau avant x1
Connecteur d'entrée CD x1 Connecteur d'entrée CD x1
Connecteur de sortie S/PDIF x1 Connecteur de sortie S/PDIF x1
Embase de ventilateur UC x1 Embase de ventilateur UC x1
Embase de ventilateur système x1 Embase de ventilateur système x1
Embase d'effacement CMO S x1 Embase d'effacement CMO S x1
Connecteur USB x3 Connec teur USB x3
Connecteur de Port série x1 Connecteur de Port série x1
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(24 broches)
Connecteur
embarqué
Connecteur d'alimentation x1
(4 broches)
Connecteur d'alimentation x1
(4 broches)
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB x4
Fiche audio x3
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB x4
Fiche audio x3
Dimensions
de la carte
190 mm (l) X 244 mm (H) 190 mm (l) X 244 mm (H)
Fonctionnali
tés
spéciales
Pris e en charge RAID 0 / 1 / 5 / 0+1 Pris e en charge RAID 0 / 1 / 5 / 0+1
Support SE
Windows XP / VISTA
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans préavis.
Windows XP / VISTA
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans préavis.
