K8T890-A9

B. BIOS & Software

BIOS

Award legal BIOS.

Supports APM1.2.

Supports ACPI.

Supports USB Function.

Software

Supports 9

Touch

, Flasher

, WinFlasher

, and

Warpspeeder

1.2 PACKAGE LIST

FDD cable x1

HDD cable x1

User’s Manual x1

Fully Setup Driver CD x1

Rear I/O panel for ATX case x1

USB 2.0 cable x1 (optional)

Serial ATA cable x2 (optional)

S/PDIF out cable x1 (optional)
