K8VGA-M
8
2.2 FAN HEADERS
CPU FAN Header: JCFAN1
Pin Assignment
1 Ground
2 +12V
1
JCFAN1
3 FAN RPM rate sense
System Fan Header: JSFAN1
Pin Assignment
1 Ground
2 +12V
1
JSFAN1
3 FAN RPM rate sense
North-bridge Fan Header: JNFAN1 (optional)
Pin Assignment
1 Ground
2 +12V
1
JNFAN1
3 FAN RPM rate sense
Note:
The JCFAN1, JSFAN1, and JNFAN1 support 3-pin head connector.
When connecting with wires onto connectors, please note that the red
wire is the positive and should be connected to pin#2, and the black
wire is Ground and should be connected to GND.
