![Biostar K8VGA-M [3/66] Chapter 1 introduction](/views2/1712317/page3/bg3.png)
K8VGA-M
1
CHAPTER 1: INTRODUCTION
1.1 K8VGA-M FEATURES
AA.. HHaarrddwwaarree
CPU
Supports Socket 754.
Supports AMD Athlon 64/Sempron processor.
200/400/600/800 clock rates with Double Data Rate style
operation for 400/800/1200/1600 MT/s in both directions
simultaneously for Hyper Transport link.
Chipset
North bridge: VIA K8M800
South bridge: VIA VT8237
Dimensions
Micro ATX Form Factor: 24.4cm (W) x 24.4cm (L)
Main Memory
Supports 266/333/400 MHz DDR devices.
Certified DDR400+ List
- Please check the website:
http://www.biostar.com.tw/products/mainboard/board.php3?
name=K8VGA-M
Maximum memory size is 2GB.
DIMM Socket
Location
DDR Module
Total Memory
Size (MB)
DIMM1 128MB/256MB/512MB/1GB *1
DIMM2 128MB/256MB/512MB/1GB *1
Max is 2 GB.
Slots
3 x 32-bi t PCI bus m aster sl ots.
1 x AGP 8x slot
1 x CNR slot.
Super I/O
Chip: Winbond W83697HF.
Low Pin Count Interface.
Integrate hardware monitor functions.
