1-3 Specification
Interface Complaint with PCI 2.2 standard
Standards
Conformance
Compliant with 802.11b / 802.11g / 802.11n (draft 2.0)
Data Rate
IEEE 802.11b: 11/5.5/2/1M
IEEE 802.11g: 54/48/36/24/18/12/9/6
IEEE 802.11n:
300/270/243/240/216/180/162/120/108Mbps in 40Mhz mode
145/130/117/104/ 78Mbps in 20Mhz mode
Operating Mode Infrastructure / Ad-Hoc Mode / Soft-AP Mode
Security WEP 64/128bit, WPA, WPA2 , WPA-PSK , WPA2-PSK
RF Modulation
802.11b: DSSS, CCK, QPSK, BPSK
802.11g: OFDM
802.11n: 64QAM, 16QAM, QPSK, BPSK
Output Power
11b mode: 14~16dBm
11g mode: 14~16dBm
11n mode: 12~14dBm
Frequency Band 2400-2485MHz
Management Built-in utility or Windows XP Zero Configuration utility
Operating systems Windows 2000 / XP / Vista
Environmental & Mechanical Characteristics
Temperature
Operating: 0 - 55 degree C
Storage: -20 - 70 degree C
Operating Humidity
Operating: 0 - 85%
Storage: 0 - 95% Non-Condensing
Dimensions 120×45 mm (Non-Bracket)
Weight 60g
Certifications FCC, CE
