Installation Guide
15
Bauen Sie das Netzteil ins Gehäuse ein
Instale la fuente de alimentación en la carcasa
Installazione dell’alimentatore nel case
Install power supply into the case
Установите в корпус блок питания
전원 공급장치를 케이스에 설치합니다
安裝電源
安装电源
電源をケースに取り付けます
Installez la source d’alimentation dans le châssis
12
Primera Series PM01-RGB / PM01-FX
