Component size limitations
27
Primera Series PM01-RGB / PM01-FX
(4) Liquid cooling radiator limitations
360mm Radiator limitation
120MM, 140MM
240MM, 280MM
360MM
140MM
120MM
120MM, 140MM
240MM, 280MM
360MM
33MM
71.4MM
45MM
35.55MM
6.6MM
72.9MM
