Connector Definition
21
(4) RGB LED Signal Cable Connecter Guide
Primera Series PM01-RGB / PM01-FX
Bitte prüfen Sie beim Anschließen der Kabel Pinbelegung und Ausrichtung von Anschluss und Stiftleiste
Por favor, confirme la dirección y orientación del conector y pines cuando conecte los cables
Verificare la definizione e la direzione dei connettori durante il collegamento dei cavi
Please confirm the connector and pin header’s definition & direction when connecting cables
Пожалуйста, проверяйте направление разъёмов и коннекторов при подключении кабелей
케이블 연결 시 커넥터와 핀 헤더의 정의 및 방향을 확인하십시오
連接線材時務必確認接頭與pin port定義與方向相同
连接线材时务必确认接头与pin port定义与方向相同
ケーブル接続時には、コネクタおよびピンヘッダの配列および方向を確認してください
Vérifiez soigneusement les branchements réalisés au niveau des connecteurs à chaque étape de l’assemblage
