98
y Public Accessible Server
This function allows the administrator to set 40 virtual servers at most, so that the computers not belonging to
the managed network can access the servers in the managed network via WAN port IP of PLANET WLS-1280.
Please enter the “External Service Port”, “Local Server IP Address” and “Local Server Port”. According to
the different services provided, the network service can use the TCP protocol or the UDP protocol. In the Enable
column, check the desired server to enable. These settings will become effective immediately after clicking the
Apply button.
