112
4.6.1 System Status
This section provides an overview of the system for the administrator.
The description of the table is as follows:
Item
Description
Current Firmware Version
The present firmware version of PLANET WLS-1280
System Name
The system name. The default is PLANET WLS-1280
Home Page
The page to which the users are directed after initial login
success.
