3. Base Installation
3.1 Hardware Installation
3.1.1 System Requirements
y Standard 10/100BaseT including five network cables with RJ-45 connectors
y All PCs need to install the TCP/IP network protocol
3.1.2 Package Contents
The standard package of PLANET WLS-1280 includes:
y PLANET WLS-1280 x 1
y CD-ROM x 1
y Quick Installation Guide x 1
y Power Adapter (DC 12V) x 1
y Cross Over Ethernet Cable x 1
y Console Cable x 1
Warning: It is highly recommended to use all the supplies in the package instead of substituting any components by
other suppliers to guarantee best performance.
