automatic crossover. If after the AP hardware resets, PLANET WLS-1280 could not be able to connect to the AP

while connecting with a straight cable, the user have to pull out and plug-in the straight cable again. This

scenario does NOT occur while using a crossover cable.

After the hardware of PLANET WLS-1280 is installed completely, the system is ready to be configured in the

following sections.
