Restore the device:
a. Insert the paper clip or other tool and press and hold the
button down continuously.
Hold it at least 5 seconds and release the tool. Then the device has been
restored to default settings and reboot again.
7. DI/DO
Connector
The Camera provides a terminal block with 4 pins of connectors for DI and
DO. Please refer to the user’s manual for more information.
Alarm I/O connectors:
Pin Function
1 12VDC power supply (50mA maximum)
2 Alarm Input
3 GND
4 Alarm Output
Note:
The pin 1 is located at the right side of terminal block from rear view.
10
