2.2 Physical Description
2.2.1 Terminal Connections
2. LAN LED
1. Power LED
3. Microphone
Front View
1 Power LED This LED is used to indicate whether DC power is on or not.
2 LAN LED This LED will be flashing while network accessing via Ethernet.
3 Microphone
The Camera has built-in an internal microphone. This microphone is
hidden in the pinhole located on the front panel.
