• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
14
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ14P
NOTES
1 The above table shows the average value of conditions which may occur.
TC: Total capacity (kW); PI: Power Input (kW) (Comp.+Outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor air
temp.
(°CDB)
Indoor air temp.(°CWB)
14.0 16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
KW KW KW KW KW KW KW KW KW KW KW KW KW KW
130%
(780)
10 35.1 5.25 41.9 6.43 48.6 7.64 52.0 7.64 53.0 7.64 54.3 7.64 55.6 7.64
12 35.1 5.35 41.9 6.55 48.6 7.79 51.7 7.79 52.4 7.79 53.6 7.79 54.9 7.79
14 35.1 5.45 41.9 6.67 48.6 7.94 51.0 7.94 51.7 7.94 52.9 7.94 54.2 7.94
16 35.1 5.55 41.9 6.80 48.6 8.09 50.4 8.09 51.0 8.09 52.3 8.09 53.5 8.09
18 35.1 5.66 41.9 6.94 48.6 8.61 49.7 8.79 50.3 8.83 51.6 8.91 52.8 8.99
20 35.1 5.77 41.9 7.39 48.4 9.17 49.0 9.22 49.6 9.26 50.9 9.34 52.2 9.43
21 35.1 5.94 41.9 7.65 48.0 9.39 48.7 9.43 49.3 9.47 50.6 9.56 51.8 9.65
23 35.1 6.35 41.9 8.21 47.3 9.81 48.0 9.86 48.6 9.91 49.9 10.00 51.1 10.1
25 35.16.8041.98.7946.710.247.310.347.910.349.210.450.510.5
27 35.17.2641.99.4046.010.746.610.747.210.848.510.949.811.0
29 35.17.7541.910.045.311.145.911.246.611.247.811.349.111.4
31 35.18.2641.910.744.611.545.211.645.911.747.111.848.411.9
33 35.18.8141.911.543.912.044.612.045.212.146.512.247.712.3
35 35.19.3841.912.243.212.443.912.544.512.545.812.747.012.8
37 35.19.9941.312.742.612.843.212.943.813.045.113.146.413.3
39 35.1 10.6 40.6 13.1 41.9 13.3 42.5 13.4 43.1 13.4 44.4 13.6 45.7 13.7
120%
(720)
10 32.4 4.80 38.6 5.86 44.9 6.97 48.0 7.53 51.1 7.53 53.4 7.53 54.6 7.53
12 32.4 4.88 38.6 5.97 44.9 7.10 48.0 7.67 51.1 7.67 52.7 7.67 53.9 7.67
14 32.4 4.97 38.6 6.08 44.9 7.23 48.0 7.82 50.9 7.82 52.0 7.82 53.2 7.82
16 32.4 5.07 38.6 6.20 44.9 7.38 48.0 7.97 50.2 7.97 51.4 7.97 52.5 7.97
18 32.4 5.17 38.6 6.32 44.9 7.63 48.0 8.44 49.5 8.78 50.7 8.85 51.9 8.92
20 32.4 5.27 38.6 6.57 44.9 8.20 48.0 9.08 48.8 9.20 50.0 9.28 51.2 9.36
21 32.4 5.32 38.6 6.81 44.9 8.50 47.9 9.38 48.5 9.42 49.7 9.50 50.8 9.58
23 32.45.6838.67.2944.99.1147.29.8047.89.8549.09.9350.110.0
25 32.46.0738.67.8144.99.7646.510.247.110.348.310.449.510.5
27 32.46.4838.68.3544.910.445.910.746.410.747.610.848.810.9
29 32.46.9138.68.9144.611.045.211.145.811.146.911.248.111.4
31 32.47.3738.69.5143.911.544.511.545.111.646.211.747.411.8
33 32.47.8538.610.143.211.943.812.044.412.045.612.146.712.2
35 32.48.3638.610.842.512.343.112.443.712.544.912.646.012.7
37 32.48.8938.611.541.912.842.412.843.012.944.213.045.413.2
39 32.49.4638.612.341.213.241.813.342.313.343.513.544.713.6
110%
(660)
10 29.7 4.36 35.4 5.30 41.1 6.30 44.0 6.81 46.9 7.32 52.5 7.49 53.6 7.49
12 29.7 4.43 35.4 5.40 41.1 6.42 44.0 6.94 46.9 7.46 51.8 7.64 52.9 7.64
14 29.7 4.51 35.4 5.50 41.1 6.54 44.0 7.07 46.9 7.61 51.2 7.78 52.2 7.78
16 29.7 4.60 35.4 5.61 41.1 6.67 44.0 7.21 46.9 7.75 50.5 7.93 51.5 7.93
18 29.7 4.69 35.4 5.72 41.1 6.80 44.0 7.41 46.9 8.14 49.8 8.79 50.9 8.86
20 29.7 4.78 35.4 5.83 41.1 7.20 44.0 7.96 46.9 8.75 49.1 9.22 50.2 9.29
21 29.7 4.82 35.4 6.01 41.1 7.46 44.0 8.25 46.9 9.07 48.8 9.44 49.8 9.51
23 29.7 5.05 35.4 6.44 41.1 8.00 44.0 8.84 46.9 9.73 48.1 9.87 49.2 9.95
25 29.75.3935.46.8841.18.5644.09.4746.310.247.410.348.510.4
27 29.75.7535.47.3541.19.1644.010.145.610.646.710.747.810.8
29 29.76.1335.47.8541.19.7944.010.845.011.146.011.247.111.3
31 29.76.5335.48.3741.110.543.711.544.311.545.311.646.411.7
33 29.76.9535.48.9241.111.243.111.943.611.944.712.045.712.2
35 29.77.3935.49.5141.111.942.412.342.912.444.012.545.112.6
37 29.77.8635.410.141.112.741.712.842.212.843.312.944.413.0
39 29.78.3635.410.840.513.141.013.241.513.342.613.443.713.5
100%
(600)
10 27.0 3.93 32.2 4.76 37.4 5.64 40.0 6.10 42.6 6.56 47.8 7.49 52.6 7.49
12 27.0 4.00 32.2 4.85 37.4 5.75 40.0 6.21 42.6 6.68 47.8 7.64 51.9 7.64
14 27.0 4.07 32.2 4.94 37.4 5.86 40.0 6.33 42.6 6.81 47.8 7.78 51.2 7.78
16 27.0 4.14 32.2 5.03 37.4 5.97 40.0 6.45 42.6 6.94 47.8 7.93 50.6 7.93
18 27.0 4.22 32.2 5.13 37.4 6.09 40.0 6.58 42.6 7.08 47.8 8.39 49.9 8.80
20 27.0 4.30 32.2 5.23 37.4 6.27 40.0 6.91 42.6 7.59 47.8 9.02 49.2 9.23
21 27.0 4.34 32.2 5.28 37.4 6.50 40.0 7.16 42.6 7.86 47.8 9.35 48.8 9.44
23 27.0 4.46 32.2 5.64 37.4 6.96 40.0 7.67 42.6 8.43 47.2 9.80 48.2 9.87
25 27.04.7532.26.0237.47.4440.08.2142.69.0246.510.247.510.3
27 27.05.0732.26.4337.47.9640.08.7842.69.6545.810.746.810.7
29 27.05.4032.26.8637.48.5040.09.3842.610.345.111.146.111.2
31 27.05.7432.27.3137.49.0740.010.042.611.044.511.545.411.6
33 27.06.1132.27.7837.49.6740.010.742.611.843.812.044.712.1
35 27.06.4932.28.2837.410.340.011.442.112.343.112.444.112.5
37 27.06.8932.28.8237.411.040.012.241.412.742.412.843.412.9
39 27.07.3232.29.3837.411.740.013.040.713.241.713.342.713.4
