Daikin REYQ16PY1B [43/137] Capacity tables
![Daikin REYQ14PY1B [43/137] Capacity tables](/views2/1713627/page43/bg2b.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
42
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ42P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (1365) 10 104 16.5 123 20.2 143 24.0 149 24.0 150 24.0 154 24.0 158 24.0
12 104 16.8 123 20.6 143 24.5 147 24.5 149 24.5 152 24.5 156 24.5
14 104 17.1 123 21.0 143 24.8 145 24.8 147 24.8 150 24.8 154 24.8
16 104 17.4 123 21.4 141 24.6 143 24.7 145 24.7 148 24.8 152 24.8
18 104 17.8 123 21.8 139 25.6 141 25.7 143 25.8 147 26.1 150 26.3
20 104 18.1 123 23.2 137 26.8 139 27.0 141 27.1 145 27.4 148 27.6
21 104 18.6 123 24.0 136 27.5 138 27.6 140 27.7 144 28.0 147 28.3
23 104 20.0 123 25.8 134 28.7 136 28.9 138 29.0 142 29.3 145 29.6
25 104 21.3 123 27.6 132 30.0 134 30.1 136 30.3 140 30.6 144 30.9
27 104 22.8 123 29.5 130 31.2 132 31.4 134 31.6 138 31.9 142 32.2
29 104 24.3 123 31.5 129 32.5 130 32.7 132 32.8 136 33.2 140 33.5
31 104 25.9 123 33.4 127 33.8 128 33.9 130 34.1 134 34.5 138 34.9
33 104 27.7 121 34.7 125 35.0 127 35.2 128 35.4 132 35.8 136 36.2
35 104 29.5 119 35.9 123 36.3 125 36.5 126 36.7 130 37.1 134 37.6
37 104 31.4 117 37.2 121 37.6 123 37.8 125 38.0 128 38.5 132 38.9
39 104 33.4 115 38.5 119 38.9 121 39.1 123 39.4 126 39.8 130 40.3
120 (1260) 10 95.6 15.1 114 18.4 132 21.9 142 23.6 148 23.6 152 23.6 155 23.6
12 95.6 15.3 114 18.7 132 22.3 142 24.1 146 24.1 150 24.1 153 24.1
14 95.6 15.6 114 19.1 132 22.7 142 24.6 144 24.6 148 24.6 151 24.6
16 95.6 15.9 114 19.5 132 23.2 141 24.7 142 24.7 146 24.8 149 24.8
18 95.6 16.2 114 19.9 132 24.0 139 25.6 140 25.7 144 25.9 147 26.1
20 95.6 16.5 114 20.6 132 25.7 137 26.8 139 26.9 142 27.2 145 27.4
21 95.6 16.7 114 21.4 132 26.7 136 27.4 138 27.6 141 27.8 144 28.1
23 95.6 17.8 114 22.9 132 28.5 134 28.7 136 28.8 139 29.1 143 29.4
25 95.6 19.1 114 24.5 130 29.8 132 29.9 134 30.1 137 30.4 141 30.7
27 95.6 20.4 114 26.2 128 31.0 130 31.2 132 31.3 135 31.7 139 32.0
29 95.6 21.7 114 28.0 126 32.3 128 32.5 130 32.6 133 32.9 137 33.3
31 95.6 23.1 114 29.9 125 33.6 126 33.7 128 33.9 131 34.2 135 34.6
33 95.6 24.7 114 31.9 123 34.8 124 35.0 126 35.2 130 35.5 133 35.9
35 95.6 26.2 114 34.0 121 36.1 122 36.3 124 36.5 128 36.9 131 37.2
37 95.6 27.9 114 36.2 119 37.4 120 37.6 122 37.8 126 38.2 129 38.6
39 95.6 29.7 113 38.2 117 38.7 119 38.9 120 39.1 124 39.5 127 39.9
110 (1155) 10 87.6 13.7 104 16.7 121 19.8 130 21.4 138 23.0 149 23.5 152 23.5
12 87.6 13.9 104 17.0 121 20.2 130 21.8 138 23.4 147 24.0 150 24.0
14 87.6 14.2 104 17.3 121 20.5 130 22.2 138 23.9 145 24.4 148 24.4
16 87.6 14.4 104 17.6 121 20.9 130 22.6 138 24.3 143 24.8 146 24.8
18 87.6 14.7 104 18.0 121 21.4 130 23.3 138 25.5 141 25.7 144 25.9
20 87.6 15.0 104 18.3 121 22.6 130 25.0 136 26.8 139 27.0 143 27.2
21 87.6 15.1 104 18.9 121 23.4 130 25.9 135 27.4 138 27.6 142 27.9
23 87.6 15.9 104 20.2 121 25.1 130 27.8 133 28.6 136 28.9 140 29.1
25 87.6 16.9 104 21.6 121 26.9 130 29.8 131 29.9 135 30.1 138 30.4
27 87.6 18.1 104 23.1 121 28.8 128 31.0 129 31.1 133 31.4 136 31.7
29 87.6 19.3 104 24.7 121 30.7 126 32.3 128 32.4 131 32.7 134 33.0
31 87.6 20.5 104 26.3 121 32.8 124 33.5 126 33.7 129 34.0 132 34.3
33 87.6 21.8 104 28.0 121 34.6 122 34.8 124 34.9 127 35.3 130 35.6
35 87.6 23.2 104 29.9 119 35.9 120 36.0 122 36.2 125 36.6 128 36.9
37 87.6 24.7 104 31.8 117 37.1 118 37.3 120 37.5 123 37.9 126 38.2
39 87.6 26.2 104 33.9 115 38.4 116 38.6 118 38.8 121 39.2 124 39.6
100 (1050) 10 79.6 12.3 95.0 15.0 110 17.7 118 19.1 126 20.6 141 23.5 149 23.5
12 79.6 12.6 95.0 15.2 110 18.1 118 19.5 126 21.0 141 24.0 147 24.0
14 79.6 12.8 95.0 15.5 110 18.4 118 19.9 126 21.4 141 24.4 145 24.4
16 79.6 13.0 95.0 15.8 110 18.8 118 20.3 126 21.8 141 24.8 143 24.8
18 79.6 13.2 95.0 16.1 110 19.1 118 20.7 126 22.2 139 25.6 141 25.8
20 79.6 13.5 95.0 16.4 110 19.7 118 21.7 126 23.8 137 26.8 140 27.0
21 79.6 13.6 95.0 16.6 110 20.4 118 22.5 126 24.7 136 27.4 139 27.6
23 79.6 14.0 95.0 17.7 110 21.9 118 24.1 126 26.5 134 28.7 137 28.9
25 79.6 14.9 95.0 18.9 110 23.4 118 25.8 126 28.3 132 29.9 135 30.2
27 79.6 15.9 95.0 20.2 110 25.0 118 27.6 126 30.3 130 31.2 133 31.4
29 79.6 16.9 95.0 21.5 110 26.7 118 29.5 125 32.2 128 32.5 131 32.7
31 79.6 18.0 95.0 22.9 110 28.5 118 31.5 123 33.4 126 33.7 129 34.0
33 79.6 19.2 95.0 24.4 110 30.4 118 33.6 121 34.7 124 35.0 127 35.3
35 79.6 20.4 95.0 26.0 110 32.4 118 35.8 119 36.0 122 36.3 125 36.6
37 79.6 21.6 95.0 27.7 110 34.5 116 37.1 118 37.2 120 37.6 123 37.9
39 79.6 23.0 95.0 29.4 110 36.7 114 38.3 116 38.5 118 38.9 121 39.2
NOTES
1 The above table shows the average value of conditions which may occur.
