Power & LAN LED (green color)

This LED is used to indicate whether DC power is on or not. In addition, this LED

will be ashing while network accessing via Ethernet.

DI/DO Connector

The Camera provides a terminal block with 4 pins of connectors for DI and DO.

Please refer to the Appendix B in this manual for more information.

External Microphone

The Camera also supports external microphone. User can plug in an external

microphone to pick up voice more.

2.2.3 Installation Steps

1. Attach the Camera with the included stand

2. Fix camera to desired location with stand

3. Plug an Ethernet cable into the Camera

Connect an Ethernet cable to the LAN socket located on the camera’s rear and

attach it to the network.

4. Connect the external power supply to Camera

Connect the attached power adapter to the DC power jack of the camera. Note:

Use the power adapter, 12VDC, included in the package and connect it to wall

outlet for AC power.

Once you have installed the camera well and powered it on, the power LED will

turn on. It means the system is booting up successfully. Furthermore, if you

have a proper network connection, and access to the camera, the LED will ash

green under wired mode.

5. Done
