Case Storage Series CS01-HS
9
Installation Chart
06
Installieren Sie die flache Erweiterungskarte.
Instale la tarjeta de expansión de perfil bajo.
Installare la scheda di espansione a basso profilo.
Install low profile expansion card.
Установите низкопрофильную плату расширения.
安裝Low profile擴充卡。
安装Low profile扩充卡。
로우 프로필 확장 카드를 설치합니다.
ロープロファイル拡張カードを装着します。
Installer une carte d'extension de faible encombrement.
