SilverStone SST-CS01B-HS [4/28] Disassemble chart
![SilverStone SST-CS01B-HS [4/28] Disassemble chart](/views2/1714387/page4/bg4.png)
Case Storage Series CS01-HS
Disassemble Chart
2
PICTURE PURPOSE
HDD - SPRING-CLIP
THUMB - SCREW
ITEM
M3 - 4 - SCREW - NI
MANUAL
STICKER
632 - 5 - SCREW - NI
Secure motherboard and PSU
Secure side panel
Metal shrapnel to support 2.5" HDD hot-swap tray
Secure 2.5" SSD/HDD
Description HDD content
Fan Filter x 1
Side Cover x 2
Power LED
Reset Button
Power Button
HDD LED
USB3.0
12025 Fan x 1
2.5" HDD HotSwap x 6
2.5" HDD Tray x 2
Extended AC
power cord
