SilverStone SST-CS01B-HS [7/28] Installation chart
![SilverStone SST-CS01B-HS [7/28] Installation chart](/views2/1714387/page7/bg7.png)
Case Storage Series CS01-HS
5
Installation Chart
02
Lösen Sie die Fixierschrauben der Hot-Swapping-Baugruppe und nehmen Sie sie heraus.
Afloje los tornillos que sujetan el ensamblaje de montaje en caliente para retirarlo.
Allentare le viti che fissano il gruppo hot-swap per rimuoverlo.
Loosen screws holding the hot-swap assembly to remove it.
Отверните винты крепления блока "горячей" замены и извлеките его.P
鬆開固定螺絲，並向上取出熱插拔硬碟模組。
松开固定螺丝，并向上取出热插入硬盘模块。
핫스왑 어셈블리를 고정하는 나사를 풀어 어셈블리를 분리합니다.
ホットスワップアセンブリを固定しているネジを緩めて取り外します。
Dévissez les vis qui retiennent l'ensemble échangeable à chaud pour enlever celui-ci.
