Ariston ECOT7D 149 [14/60] Installation

Installation

! Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the washing machine to

inform the new owner as to its operation and

features.

! Read these instructions carefully: they contain

vital information on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the washing machine.

2. Check whether the washing machine has

been damaged during transport. If this is the

case, do not install it and contact your retailer.

3. Remove the four

protective screws and

the rubber washer with

the respective spacer,

situated on the rear

of the appliance (see

figure).

4. Seal the gaps using

the plastic plugs provi-

ded.

5. Keep all the parts:

you will need them

again if the washing

machine needs to be

moved to another lo-

cation.

Warning: should the screws be re-used, make

sure you fasten the shorter ones at the top.

! Packaging materials are not children’s toys.

Levelling

1. Install the washing machine on a flat sturdy

floor, without resting it up against walls, furniture

cabinets or other.

2. If the floor is not per-

fectly level, compensa-

te for any unevenness

by tightening or loo-

sening the adjustable

front feet (see figure);

the angle of inclination,

measured according to

the worktop, must not

exceed 2°.

Levelling your applian-

ce correctly will provide it with stability and

avoid any vibrations, noise and shifting during

operation.

If it is placed on a fitted or loose carpet, adjust

the feet in such a way as to allow enough room

for ventilation beneath the washing machine.

Putting your appliance in place and

moving it.

I f y o u r w a s h i n g

machine is equipped

with a special set of

retractable wheels

you can easy move it.

To lower the wheels

and thus move the

appliance effortlessly,

just pull the lever,

situated on the left-

hand side beneath the base. Once the appliance

is in the required position, put the lever back in

place. The washing machine is now firmly in

place (see figure).

Electric and water connections

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tab using

a ¾ gas threaded con-

nection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the other

end of the water inlet

hose to the washing

machine,

screwing it onto the ap-

pliance’s cold water in-

let, situated on the top

right-hand side on the

rear of the appliance

(see figure).

3. Make sure there are no kinks or bends in the

hose.

! The water pressure at the tap must be within

the values indicated in the Technical details

table (on the next page).

! If the water inlet hose is not long enough,

contact a specialist store or an authorised

serviceman.

! Never use hoses that have already been used.
