Planet VIP-1680 [32/91] Dialing plan to h 23 protocol
![Planet VIP-1680FS [32/91] Dialing plan to h 23 protocol](/views2/1071516/page32/bg20.png)
32
Voice Cap Prefix
Let user set prefix number in RRQ nonstandard voicecap
entry.
RAS Port Adjustment
In H.323 standard the RAS default port number is 1719.
The VoIP gateway provides user to change RAS port
number to meet the network environment.(Some area
carrier blocks or forbidden the default port number)
Q.931 Port Adjustment
In H.323 standard the default Q.931 port number is 1720.
The VoIP gateway provides user to change Q.931 port to
meet the network environment. (Some area carrier blocks
or forbidden the default port number)
H.323 Call Pass through NAT
H.323 ID
Sets the unique name of this Gateway, that is
communicated as part of H.323 messaging.
H.323 Pass Through NAT
method
1. Disable : The Gateway operates in public IP address
2. Auto Detection: When the Gateway register to GNU
Gatekeeper, please select this option.
3. Manual Setting: When the Gateway registers to H.323
Gatekeeper and operate under NAT (enable DMZ), please
select this option and key in IP address.
Dialing Plan to H.323 protocol
The “Dialing plan” needs setting when the user uses the method of Peer-to-Peer H.323 VoIP call or
registering H.323 Gatekeeper mode. The H.323 Dialing Plan has three kinds of directions: Outgoing
(call out) and Incoming (call in) and PSTN route.
Outgoing Dial Plan
Peer-to-Peer call mode: Effective
Registering to H.323 Gatekeeper mode: Effective
Incoming Dial Plan
Peer-to-Peer call mode: Effective
Registering to H.323 Gatekeeper mode:
The leading number would register to H.323 Gatekeeper
PSTN Route Dial Plan
Peer-to-Peer call mode: The same as the Incoming dial plan
Registering to H.323 Gatekeeper mode: The leading number
would NOT register to H.323 Gatekeeper
In the “Outgoing Dial Plan Configurations” settings: Maximum Entries : 50
“Outbound number” is the leading digits of the call out dialing number.
“Length of Number” has two text fields need filled: “Min Length” and “Max Length” is the
min/max allowed length you can dial.
