List of Electrical and Functional Parts SiUS39-601
230 Appendix
3. List of Electrical and Functional Parts
3.1 Outdoor Unit
3.1.1 RXYQ72M, 96MTJU
Item Name Symbol
Model
RXYQ72M, 96MTJU
Compressor Inverter Type M1C JT100FCVDKT@3
STD.1 Type M2C JT170FCKTJ@3
Crankcase heater (INV) E1HC 240V 33W
Crankcase heater (STD.1) E2HC 240V 33W
Crankcase heater (STD.2) E3HC —
OC protection device for STD compressor — 28.8A
Fan motor Motor M1F 0.75kw
OC protection device — 3.2A
Functional parts Electronic expansion valve
(Main)
Cooling Y1E 0pls
Heating PI control
Electronic expansion valve
(Subcool)
Cooling Y2E PI control
Heating 0pls
Solenoid valve (Hot gas) Y1S TEV1620DQ2
Solenoid valve (External multi oil) Y2S
TEV1620DQ2
Solenoid valve (Receiver gas charge) Y3S TEV1620DQ2
Solenoid valve (Receiver gas discharge) Y4S VPV-603D
Solenoid valve (Non-operating unit gas discharge)
Y5S TEV1620DQ2
Solenoid valve (Non-operating unit liquid pipe close)
Y6S VPV-803DQ50
4 way valve Y7S VHV0404
Pressure-related
parts
Pressure switch (INV) S1PH PS80 ON : 551+0/-21.8psi OFF : 413±21.8psi
Pressure switch (STD1) S2PH
PS80
ON : 551+0/-21.8psi
OFF : 413±21.8psi
Pressure switch (STD2) S3PH —
Fusible plug — FPGD-3D 158 to 167°F
Pressure sensor (HP) S1NPH PS8051A 0 to 601.9psi
Pressure sensor (LP) S1NPL PS8051A -14.5 to 246.6psi
Thermistor INV PCB For fin R1T 3.5 to 360Ω
Main PCB For outdoor air R1T 3.5 to 360Ω
For suction pipe R2T 3.5 to 360Ω
For discharge pipe (INV) R31T 3.5 to 400Ω
For discharge pipe (STD.1) R32T 3.5 to 400Ω
For discharge pipe (STD.2) R33T 3.5 to 400Ω
For heat exchanger R4T 3.5 to 360Ω
For subcooling heat exchanger R5T 3.5 to 360Ω
For receiver liquid pipe R6T 3.5 to 360Ω
For equalizing pipe R7T 3.5 to 360Ω
Others Fuse (A1P) F1, 2U 250VAC 10A Class B
